Three-Phase Wiring Diagrams. ALWAYS USE WIRING DIAGRAM SUPPLIED ON MOTOR NAMEPLATE. - colored leads are only applicable on the NEW ROLLED STEEL motor lines -. Yes, it is possible to connect 3 phase motors in star as well as delta connection if you have winding ends noted well i.e R-phase: R1- coil -R2 similarly for B phase and y phase. Now you have 6 winding ends R1,R2,Y1,Y2,B1,B2; Delta Connection Con. A 3 phase motor is typically a more powerful and cost effective alternative to its single phase and dual wire counterparts. This wiring system can run the motor in either direction, which extends its life.

Identifying 230 and 460 Connections - York Repair Inc

Mark Lamendola May 24, Motors can be wired delta or wye. Which arrangement do you choose, and how do you do it? The delta or wye connection is about the desired motor starting arrangement, not how the motor is wound.

How to Wire a 3 Phase Motor

Ideally, you will be connecting motors per an installation drawing. Your first task is to identify how many leads the motor has. Typically, the motor will click here a 6-lead or 9-lead motor. Motors with six leads are nearly always single-voltage motors. Such motors might be dual-winding motors, in which case you can wire them for a part winding start. You can connect them for a delta start or a wye start.

Connect motor lead 1 to L1 typically blackmotor lead 2 to L2 typically redand motor lead 3 to L3 typically blue. Connect the other motor leads 4, 5, and 6 together.

Examine the motor nameplate for wiring information. This is a type of relay that incorporates an over-current trip. Intertwine the second, fourth, and eighth wires and slip on a wire nut before attaching to the L2 terminal.

Instead, connect motor lead 1 and 6 to L1 typically blackmotor lead 2 and 4 to L2 typically redand motor lead 3 and 5 to L3 typically blue. Three-phase motors with 9 leads are nearly always dual-voltage motors. Connecting these is a bit more complicated, and mistakes are actually common. But there are exceptions IEC motors, for example. For the wye start, dual voltage nine lead motor on the lower voltage, connect 1 and 7 to L1, 2 and 8 to L2, and 3 and 9 to L3.

Connect the remaining leads 4, 5, and 6 together. For the higher voltage, connect 1 to L1, 2 to L2, and 3 to L3.

How Do You Hook Up A 3 Phase Motor

Connect 4 to 7, 5 to 8, and 6 to 9. For the delta start, dual voltage nine lead motor on the lower voltage, connect 1, 6, and 7 to L1.

Connect 2, 4, and 8 to L2. Connect 3, 5, and 9 to L3. To avoid confusion obtain a pocket motor wiring guide and refer to it while performing the work. We mentioned a catch, earlier.

Connect motor leads 2, 8 and 4 to the red L2 conductor. Note that this must be the power supply ground conductor, not a wire leading to a ground rod nearby. However, they work well and can usually be configured to give "soft start", which is desirable in some applications. Examine the motor nameplate for wiring information. Step 5 Swap any two line connections to reverse the motor rotation.

That drawing we said to follow could be wrong. Before you connect any wires, check the drawing carefully. Before you actually make any bolted connections, verify the correct rotation using a rotation tester.

How Do You Hook Up A 3 Phase Motor

Note that this must be the power supply ground conductor, not a wire leading to a ground rod nearby. Electrical Testing brought to you by. Follow installation drawings, but if those aren't available, determine how many leads a motor has before installing it.

Installation Tips Motors Training. More information about text formats.

Text format Comments Plain text. Web page addresses and e-mail addresses turn into links automatically. Lines and paragraphs break automatically. Tip of the Week: Is your voltage imbalance excessive? Check Those Screw Terminal Terminations.

How to Wire a High & Low Voltage Three-Phase Motor
